Dynamic timber width interval

From CutLog version 6.42 you have possibility to define size of timber a little bit easier.

In case, you need to define for one thickness more board sizes with different width, you are able to use new feature called "width interval"

By default is this feature disabled, so in case you want to use it, you have to enable it in settings menu:


Enable timber width interval

Then in product window you can define interval of width for each size:

In this example we have defined set of board sizes for optimization. All have thickness 50mm and width from 50 to 150mm with increment 10mm and we also need to use this set in center boards. as result we get sizes:

50x50, 50x60x 50x70... 50x140, 50x150

It is great, because you don't need to enter all those sizes manually.
